Salt In. Clean Chlorine Out.
Smart salt chlorine generators for pools up to 60,000 gallons. Salt water flows in, the titanium cell turns it into pure chlorine, and your pool stays clear automatically.
Professional-Grade Salt Chlorination
Upgrade your pool maintenance with our advanced smart salt chlorination series. Premium titanium plates, WiFi app control and automatic self-cleaning deliver professional-grade sanitation with precision output control — available in 30, 40 and 50 g/h models (about 1.6, 2.1 and 2.6 lb of chlorine per day).
Multiple Protection
Seven layers of protection keep the salt chlorinator — and your equipment — running safely.
Overvoltage Protection
Shuts down safely during voltage spikes.
Overcurrent Protection
Limits current to protect the cell and board.
Water Flow Detection
Only generates chlorine when water is flowing.
Soft Start
Gentle power-up extends component life.
7-Layer ProtectionOverheat Protection
Monitors temperature and throttles back if needed.
Low Salt Alarm
Alerts you when salt drops below 2,700 ppm.
Short Circuit Protection
Instantly cuts power if a short is detected.
Steady Chlorine. Longer Cell Life.
Chlorine production and current stay stable regardless of water temperature or salinity. Stable voltage on the cell protects the rare-metal coating on the titanium plates, so the cell lasts longer and output stays consistent.
Coral Chlor™
Typical Cell
✓ Coral Chlor™ — smooth straight-through passage
Scale is washed straight through and out — nothing collects inside the cell.
✕ Designs with a low chamber
Scale sinks and builds up, shortening service life.
Less Scale. Less Maintenance.
The Coral Chlor™ cell uses a smooth, straight water passage so mineral scale is washed away instead of settling. Combined with automatic self-cleaning, it reduces scale buildup and extends the cell’s service life.
Specifications
| Specification | CC300A | CC400A | CC500A |
|---|---|---|---|
| Chlorine Output | 30 g/h 0.066 lb/h · 1.59 lb/day | 40 g/h 0.088 lb/h · 2.12 lb/day | 50 g/h 0.110 lb/h · 2.65 lb/day |
| Pool Size | 25,000 – 40,000 gal | 35,000 – 50,000 gal | 40,000 – 60,000 gal |
| Output Range | 5% – 100% adjustable | ||
| Working Voltage | DC 30V | ||
| Cell | Titanium plates, self-cleaning, 7,000 – 10,000 hr life | ||
| Plumbing | 1.5″ or 2″ PVC | ||
| Salt Level | Add salt below 2,700 ppm · do not exceed 5,500 ppm | ||
| Water Chemistry | pH 7.2 – 7.6 · Cyanuric acid 30 – 50 ppm | ||
| Control | Built-in WiFi app (2.4 GHz) with diagnostic alarms | ||
| Dimensions | 337 × 160 × 120 mm (13.3″ × 6.3″ × 4.7″) | ||
| Waterproof Rating | IP25 | ||
| Warranty | 2 years (professional installation required) | ||
